MAGS MCW50 Heavy-Duty Curtain Wall System
MAGS MCW50 is a robust curtain wall system engineered for demanding architectural applications. This heavy-duty system provides exceptional structural performance, making it suitable for high-rise buildings and projects with large glass areas. The MCW50 system offers superior weather resistance and thermal insulation while maintaining slim profiles for maximum transparency. With its advanced engineering and versatile design options, MCW50 enables architects to create impressive building facades that withstand challenging environmental conditions without compromising on aesthetics.
Performance
Comfort
Air tightnessClass 4 (EN 12207)
AcousticsRw up to 45 dB
Water tightnessClass E1500 (EN 12208)
Wind load resistanceClass C5/B5 (EN 12210)
Safety
Burglar resistanceRC3
* Note: Performances and properties may be different depending on the profile combinations
Properties
Max. dimensions & weight
max panel height6000 mm
max panel width3600 mm
max panel weight800 kg
mullion spacingUp to 2000 mm
Glazing
min glass thickness8 mm
max glass thickness80 mm
max glass weight800 kg
