MS50 Vertical Sliding - Image 1

MAGS MS50 VERTICAL SLIDING SYSTEM

MAGS CASEMENT DOORS SYSTEM MDTH50 is a insulated system for inward and outward opening doors, designed according to the highest European quality standards. To guarantee superior quality and performance in every situation, the system has three gasket levels for inward and outward opening doors. Through intelligent application, these multiple gaskets meet even the high air- and water tightness requirements of tropical regions. This simple, yet highly innovative design offers a very cost-efficient solution thanks to its optimised fabrication process. MDTH50 can be realised with all types of inward and outward opening doors, with an extensive choice of accessories the perfect match of building concepts.

Need help?

Search and compare products

Get Started

Performance

Comfort

Air tightness-
Acoustics-
Water tightness-
Wind load resistance-

Safety

Burglar resistance-

* Note: Performances and properties may be different depending on the profile combinations

Properties

Max. dimensions & weight

min height of vent2100 mm
min width of vent1500 mm
max height of vent4500 mm
max width of vent3000 mm
max weight of vent600 kg

Sightlines

frame height71 mm
visible vent width32 mm
vent system depth42 mm
interlocking view18 mm
visible meeting section71 mm, 42 mm
depth frame2 rail110 mm
depth frame3 rail165 mm

Glazing

rebate height15 mm
min glass thickness5 mm
glazing methodDry Glazing with EPDM or Natural Silicon
max glass thickness30 mm
