MCTH50 Casement Windows
Sliding
MAGS CASEMENT SYSTEM MCTH50 is a insulated system for inward and outward opening windows and doors, designed according to the highest European quality standards. To guarantee superior quality and performance in every situation, the system has three gasket levels for inward and outward opening windows and doors. Through intelligent application, these multiple gaskets meet even the high air- and water tightness requirements of tropical regions. This simple, yet highly innovative design offers a very cost-efficient solution thanks to its optimised fabrication process. MCTH50 can be realised with all types of inward and outward opening windows and doors, with an extensive choice of accessories the perfect match of building concepts.
Performance
Comfort
Air tightness
-
Acoustics
-
Water tightness
-
Wind load resistance
-
Safety
Burglar resistance
* Note: Performances and properties may be different depending on the profile combinations
Properties
Max. dimensions & weight
Min. height of vent
500 mm
Min. width of vent
300 mm
Max. height of vent
3000 mm
Max. width of vent
900 mm
Max. weight of vent
150 kg
Sightlines
Min. frame width (outward opening)
50 mm
Min. vent width (outward opening)
33mm, 41 mm
Min. frame-vent width (outward opening)
100 mm, 112 mm
Depth frame
50 mm
Depth vent
60 mm
Min. width T-profile
67 mm
Glazing
Rebate height
17 mm
Min. glass thickness - vent
20 mm
Glazing method
Dry Glazing with EPDM or Natural Silicon
Max. glass thickness - vent
35 mm
