MAGS CASEMENT DOORS SYSTEM MDTH50

MAGS CASEMENT DOORS SYSTEM MDTH50 is a insulated system for inward and outward opening doors, designed according to the highest European quality standards. To guarantee superior quality and performance in every situation, the system has three gasket levels for inward and outward opening doors. Through intelligent application, these multiple gaskets meet even the high air- and water tightness requirements of tropical regions. This simple, yet highly innovative design offers a very cost-efficient solution thanks to its optimised fabrication process. MDTH50 can be realised with all types of inward and outward opening doors, with an extensive choice of accessories the perfect match of building concepts.

Need help?

Search and compare products

Get Started

Performance

Comfort

Air tightness-
Acoustics-
Water tightness-
Wind load resistance-

Safety

Burglar resistance-

* Note: Performances and properties may be different depending on the profile combinations

Properties

Max. dimensions & weight

min height of vent500 mm
min width of vent300 mm
max height of vent3000 mm
max width of vent900 mm
max weight of vent150 kg

Sightlines

min frame width outward50 mm
min vent width outward41 mm
min frame vent width outward112 mm
depth frame50 mm
depth vent60 mm
min width t profile67 mm

Glazing

rebate height17 mm
min glass thickness20 mm
glazing methodDry Glazing with EPDM or Natural Silicon
max glass thickness35 mm
