MAGS 150 PANORAMIC SLIDING DOORS (Imported Hybrid System)
MAGS 150 PANORAMIC SLIDING DOORS is an advanced thermal break system featuring imported hybrid technology. The visible surface of the vertical door frame is only 25mm, creating an ultra-minimal aesthetic. This premium system features double rows of customized stainless steel pulleys, with the load-bearing capacity of a single fan reaching up to 1500kg. The micro-slit lower track design provides superior drainage performance. This high-performance panoramic sliding system combines cutting-edge engineering with thermal break technology for ultimate energy efficiency and structural integrity.
Performance
Comfort
Air tightness-
Acoustics-
Water tightness-
Wind load resistance-
Safety
Burglar resistance-
* Note: Performances and properties may be different depending on the profile combinations
Properties
Max. dimensions & weight
min height of vent1500 mm
min width of vent1500 mm
max height of vent4500 mm
max width of vent3000 mm
max weight of vent1500 kg
Sightlines
frame height60 mm
visible vent width40 mm
vent system depth50 mm
interlocking view25 mm
visible meeting section130 mm
depth frame2 rail115 mm
depth frame3 rail234 mm
Glazing
rebate height14 mm
min glass thickness5 mm
glazing methodDry Glazing with EPDM or Natural Silicon
max glass thickness45 mm
